Standard Micro Lined Wall Panel
Lined, micro-lined, and deep-lined surface type options.
Prepainted galvanized steel or aluminum inner and outer sheet alternatives.
External fixing joint detail.
Both vertical and horizontal cladding.
Fire performance according to TS EN 13501-1, B-s2; d0 for PUR insulated wall panels, B-s1; d0 for PIR insulated wall panels.
Length 2m.
Core thickness options: lined and micro-lined panels 40-50-60-70-75-80-100-120-150-180-200mm; deep lined panels 40-50-60mm.
Mineral Wool and EPS insulation alternatives besides PUR and PIR insulation.
